/ Product catalogue / Centralized air handling units / Rotary residential AHU / Vertical Units / VUTR VE EC / VUTR 200 V2E EC A21
| Unit of measurement | VUTR 200 V2E EC A21 | |
| Connected air duct size | mm | 125 |
| Phases | - | 1 |
| Minimum supply voltage | V | 230 |
| Maximum supply voltage | V | 230 |
| Power supply frequency | Hz | 50/60 |
| Rated power | W | 118 |
| Power of electrical reheater | W | 700 |
| Unit current | A | 4 |
| Maximum airflow | m³/h | 270 |
| Rotation speed at 50hz | - | 1800 |
| Sound pressure level LpA at 3 m | dB(A) | 28 |
| Heat recovery efficiency, max | % | 92 |
| Heat exchanger type | - | Rotary |
| Heat exchanger material | - | Aluminum |
| Weight | kg | 48 |
| Supply filter | - | G4, F7 |
| Extract filter | - | G4 |
| Transported air temperature (max) | °С | 40 |
| Transported air temperature (min) | °С | -25 |
| Ambient air temperature min | °С | 1 |
| Ambient air temperature max | °С | 40 |
| Ingress protection rating | - | IP22 |
| Ambient air humidity max | % | 80 |
| Ingress protection rating of the drive | - | IP44 |
| ØD | B | H | H1 | L |
|---|---|---|---|---|
| 122 | 508 | 630 | 754 | 598 |
| Name | Photo | Description |
|---|---|---|
| Vents A25 |
|
Touch screen control panel for controlling industrial and residential air handling units |
| Vents A22 |
|
Control panels for controlling industrial and residential air handling units |
| Vents A22 WiFi |
|
Control panels for controlling industrial and residential air handling units |
| Name | Photo | Description |
|---|---|---|
| Vents HV2 |
|
Humidity sensor |
| Vents HR-S |
|
Electro-mechanical humidistat |
| Name | Photo | Description |
|---|---|---|
| Vents KH-1 |
|
Kitchen hood for removing combustion products, vapors and odors from the air |
| Name | Photo | Description |
|---|---|---|
| Vents SR 125/600 |
|
Silencers made of galvanized steel filled with non-combustible sound-absorbing material |
| Vents SR 125/900 |
|
Silencers made of galvanized steel filled with non-combustible sound-absorbing material |
| Vents SR 125/1200 |
|
Silencers made of galvanized steel filled with non-combustible sound-absorbing material |
| Vents SRF 125/600 |
|
Silencers made of aluminium alloy filled with non-combustible sound-absorbing material |
| Vents SRF 125/900 |
|
Silencers made of aluminium alloy filled with non-combustible sound-absorbing material |
| Vents SRF 125/2000 |
|
Silencers made of aluminium alloy filled with non-combustible sound-absorbing material |
| Name | Photo | Description |
|---|---|---|
| Vents KOM 125 |
|
Backdraught damper with spring-loaded plates for shutting off air flow in round air ducts |
| Vents KRV 125 |
|
Air dampers for automatic air flow control in round ducts |
| Name | Photo | Description |
|---|---|---|
| Vents Belimo TF230 |
|
The actuators are designed for controlling air dampers with cross section up to 0.4 m² performing protection functions |
| Name | Photo | Description |
|---|---|---|
| Vents SF 284x103x60 G4 |
|
Panel filter G4 |
| Vents SF 284x103x60 F7 |
|
F7 panel filter |
